Stand 1. Pneumatic systems with directional valves
Stand 2. LR Mate 200IC FANUC robot
Station 3. Pneumatic systems with a sequential controller
Station 4. Station with the FESTO PLC controller
Stand 5. Computer workstation for simulating pneumatic systems on a PC
Laboratory classes cover the following topics:
- Pneumatic control systems with directional valves.
- Operation and programming of the LR Mate 200iC manipulator
- Realization of actuator control systems, combination and sequential control systems
- Realization of actuator control systems based on the cyclogram of operation on a PLC controller. Combination machine
- Implementation of control systems on a PLC controller, combining logical functions
- Single-acting and double-acting actuator control systems, logical and time functions.
